| Model |
e-STUDIO5508A |
e-STUDIO6508A |
e-STUDIO7508A |
e-STUDIO8508AC |
| General Feature |
| Copy / Print Speed (ppm) |
55 |
65 |
75 |
85 |
| Warm-up Time |
Approx. 24 sec. |
Approx. 20 sec. |
| Memory |
4 GB |
| Storage |
320GB Self-Encryption HDD |
| Dimension (W × D × H) |
955 × 698* × 1,212 mm / 37.6" × 27.5"* × 47.7" |
| Weight |
Approx. 193 kg / 425.5 lb |
| Input Paper Capacity |
Standard |
3,520 sheets |
| Maximum |
6,020 sheets |
| Available Paper Weight |
60 - 300 g/m² / 16 lb. Bond - 110lb. Cover |
| Available Paper size |
A5-R to 330 x 483mm / ST-R to 13" x 19", Banner paper (1,200 mm) |
| Document feeder |
Standard 300-sheet DSDF |
| Duplexing |
Standard |
| Finishing Option |
Multi-Position stapling finisher,Saddle Stitching Finisher |
| Copier Feature |
| First Copy Speed |
5.2 sec. |
4.5 sec. |
4.1 sec. |
| Resolution |
2,400 × 600 dpi (with soothing) |
| Multiple Copy |
Up to 9,999 |
| Printer Feature |
| Resolution |
600 × 600 dpi, 2,400 × 600 dpi (with soothing), 1,200 × 1,200 (PS only), 3,600 × 600 dpi (with soothing/PS only) |
| PDL |
PCL6, PS3, XPS |
| Interface |
Standard |
USB (High speed), 10/100/1000BASE-T |
| Option |
Wireless LAN (IEEE802.11 b/g/n), Bluetooth |
| Scanner Feature |
| Resolution |
100/150/200/300/400/600dpi |
| Scan Speed |
Up to 240 spm (Duplex) / Up to 120 spm (Simplex) (300 dpi) |
| Data format |
Standard |
TIFF, PDF, XPS, JPEG, Compressed PDF, PDF/A, Encrypted PDF |
| Option |
Searchable PDF, DOCX, EXLS, PPTX |
| Scan Protocol |
SMB, FTP, IPX/SPX, FTPS |
| Scan features |
File, Email, USB, e-Filing Box, TWAIN |
| Internet Fax |
ITU-T T.37 (Simple mode) |
| Fax Feature (option) |
| Communication mode / Modem Speed |
Super G3 / 33.6kbps |
| Data Compression |
JBIG, MMR, MR, MH |
| Number of Lines (Std. / Max.) |
1 / 2 |
| Phonebook |
3,000 stations |
| Security Feature |
| Standard |
Self-Encryption HDD, Private Print, Encrypted PDF, User Authentication, Role Based Access Control, IP/MAC address filtering, SNMPv3, SSL |
| Optional |
Data Overwrite, IPsec, FIPS certified Self-Encryption HDD |
